Quick Details

  • Products Status: Stock
  • Type: Barcode Scanner
  • Scan Element Type: Laser
  • Colour Depth: 32 Bit
  • Interface Type: USB
  • Max Paper Size: N/a
  • Optical Resolution: 4mil
  • Scan Speed: Up to 100 Scans/sec
  • Brand Name: WINSON
  • Model Number: WNL-5000
  • Place of Origin: Guangdong, China (Mainland)
  • Item: Barcode Scanner
  • Voltage Requirements: 5 VDC±10% @260mA
  • Light Source: 625nm LEDs
  • Aiming Light: 617nm LEDs
  • Scan Method: Bi-directional Scanning
  • Scan Rate: Up to 100scan/s
  • Scan Type: Laser
  • Protection Rate: IP54
  • MBTF: 53,310hours
  • Case: ABS/PC

Packaging & Delivery

Packaging Details Customized Packing (Negotiated)
Delivery Time 7-15day

Good Quality 1D Barcode Scanner USB Interface 32Bit Laser  Handheld Barcode Scanner With Low Price



Application and Solution



Clothing,

Retail chain store,

Warehouse management,

E-business,

Commercial retail,

Logistics express and file management, etc





Application and Solution
Clothing, retail chain store, warehouse management, e-business, commercial retail, logistics express and file management, etc

Basic Product Specifications
 WNL-5000
Operating indicatorsVisual1 LED(blue)
Non-visualBuzzer
CommunicationsUSB(Ver. 1.1 HID Keyboard)
PowerVoltage requirement5V± 10%
Current consumption85mA (typical use),max.150mA
Barcode scanner OpticsLight source650nm visible laser diode
Scan methodBi-directional scanning
Scan rateUp to 100scans/sec
Trigger modeManual, continuous read,multiple read, auto-trigger, serial software trigger
Reading pitch angle(pitch)-50 to 0°, 0 to +50°
(skew)-65 to 0°, 0 to +65°
(tilt)-35 to 0°, 0 to +35°
CurvatureR>15 mm (EAN8),R>20 mm (EAN13)
Min. resolutionPCS 0.9: 0.101 mm / 4 mil, Min. PCS value: 0.35
Physical Dimensions168 x 70 x 95 mm(d x w x h)
Weight body120g/ 4.24 oz (excl. cable)
CaseABS/PC, Black
DurabilityTemperature -20°to 65°C / -4°to 149°F(operation)
 -30°to 70°C /-22°to 158°F(storage)
Humidity20 - 85% (operation), 20 - 90% (storage)
Ambient light immunityFluorescent 3000 lx max, Direct sun 50,000 lx max, Incandescent 3000 lx max
Drop test1.5m/5ft drop onto concrete surface
Protection rateIP 54
Regulatory & SafetyProduct complianceCE, FCC, IEC 60825-1 Class 2, GB7247.1-2001
Enclosed itemsCable(USB,RS232), User Guide, DC power supply (RS232), scanner stand(sold separately)
Supported SymbologiesBarcode(1D)
EAN13,EAN8,UPC-A,UPCE,CODABAR(NW-7),CODE39,CODE93,INTERLEAVED_2OF5,STANDARD_2OF5,MATRIX_2OF5,CODE128,EAN128(GS1-128),CODE11,CHINESE_POST
Depth of field30 - 80 mm / 1.18 - 3.15 in (0.101 mm / 4 mil)
40 - 140 mm / 1.57 - 5.51 in (0.127 mm / 5 mil)
30 - 180 mm / 1.18 - 7.09 in (0.17 mm / 6.7 mil)
30 - 300 mm / 1.18 - 11.81 in (0.25 mm /10 mil)
40 - 550 mm / 1.57 - 21.65 in (0.5 mm / 20 mil)
80 - 750 mm / 3.15 - 29.53 in (1.0 mm / 40mil)



Features
